Cantilever Racking with Tapered Arms - Double Sided

Data Sheet:

Our Cantilever Racking with Tapered Arms is a fully welded and durable racking system, ideal for storing long items horizontally, such as pipes, steel bars and timber. These items can otherwise be difficult to store due to their size and shape.

Although each arm has a capacity of 200kg, the tapered design of the racking allows for storage of larger and heavier items at the bottom and smaller and lighter items at the top. This design is also helpful for stock order and organisation, as well as providing stability for the rack.

This racking system is an ideal storage solution for medium-weight loads in warehouses and other environments with items such as metal sheets, pipes, timber, panels, worktops and more. The double sided design both conserves and optimises storage space. To store, simply load items by spanning the gap between the beams.

We also have extension bays available for extra storage depending on your needs.

Key features and benefits:

• Fully welded construction
• Double sided design for added storage - ideal for use in central locations
• Extension bays available for added storage
• Finished in a stylish stove enamel blue
• Arms have a capacity of 200kg, suitable for storing medium capacity items

Please note that when loading racking of this type, always begin with the heaviest stock at the bottom, working up to lighter stock on the upper levels. This order is both easier and safer for users whilst loading and unloading.

The racking should always be securely fastened to the floor for safe operation.

Item specifics:

Starter bay:

• Weight (kg): 125
• Size L x D x H (mm): 2580 x 1190 x 2030
